Holmac HZC 45

The Holmac HZC 45 tree digger is a new machine with technical, mechanical characteristics, patented, and obligated to grant the best work capacity with the biggest security and results. It’s available in four models, one model with standard control valves, one model with a joystick, one model with a telescopic crane, and one model with a vertical lifting system of the blade/vibrating unit. The Holmac HZC 45 is able to cut a rootball to a diameter of 6 ft. and it has been developed to increase the drive comfort for the operator reducing the vibrations and permitting better visibility during tree-digging operations. The patented opening/forwarding system of the tracks allows to lift up trees with rootballs to 5ft in diameter.

Specifications

    • Rootball Dimensions

      • Minimum diameter: 2 ft.
      • Maximum diameter: 5 ft.
    • Machine Dimensions

      • Length (without blade): 9.5 ft.
      • Width (with closed tracks): 3.5 ft.
      • Width (with opened tracks): 5 ft.
      • Height (roll-bar included): 7 ft.
      • Weight: 7407 lbs.
    • Performance

      • Cubic capacity: 2197 cc
      • Motor: 4 cylinders turbo diesel engine, liquid-cooled
      • Power: 56 CV (41.2 Kw)
      • Tracks: Rubber
    • Speed

      • First speed: 2 mph
      • Second speed: 4 mph



Options

      • Standard control valves
      • Joystick
      • Telescopic crane
      • Vertical lifting system
