Holmac HZC 40

Holmac HZC 40

The Holmac HZC 40 is a large tree digger that includes a series of innovations. Standard vertical tip back system for lifting the root ball out of the ground. The Holmac HZC 40 has a narrow 41” wide track with a patented single action in/out to 60” and forward 14” ensures balance in any condition. It will dig more trees at the same time as other brands. This is possible with the 3 separate pump actions, this will allow a faster approach, faster digging, and faster bag & basket time. Travel speed variable from 0 to 4 mph forward and reverse, 2 ranges are controlled on the go. The blade change is simplified with blade support for 12 different blades from 16” to 55”.

Features

  • 3 Separate pump actions: approaching tree faster to place in digging position.
  • Centralized greaser: easier for maintenance.
  • Adjustable rubber tracks: Move Simultaneously for less stress or single movement in/out, and forward/back.



*Patented System*

    • 4000 Vibrations per minute blade, for better and smoother operation.
    • Forward or reverse speed 0 to 4 mph High / low range switch. Independent turn levers.
    • Rollover protection (ROP) & Seat belt.
    • Work lights front and rear.



Specifications

    • 50 HP Kubota water-cooled 4 Cylinder engine
    • Track adjustment (41” to 60”) In-Out
    • Track adjustment from the center to forward 16” for better balance
    • Two Speed (2 mph) to (4 mph) variable
    • Balance weight with a rear jack stand
    • Weight – 5,180 lbs.
    • Choice of 12 different size blades (from 16” to 55”).



Options

      • Horizontal turn blade right and left. 70 Degree, aides in quicker time to bag (Adds 1,566 lbs.)
      • Crane System
      • Additional Work Light
